Wire can be extended if necessary. Connect red wire from wet switch to 24vac of transformer.
34 Wet Switch Wiring Diagram Wiring Diagram List
Wet switch flood detector wiring diagram. Diversitech ws 1 wet switch flood detector the wet switch flood detector is a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. It turns the system off when moisture due to condensate or drain leaks is detected. Diversitech ws 1 wet switch flood detector note. Reset simply by drying the absorbent pad with a paper towel and pressing the reset switch. Ws 1 wet switch flood detector led indicators wet switch test reset buttons. A lit led indicates the wet switch is activated and has turned the unit off.
Connect black wire from wet switch to same wire on transformer where common was cut. Route the cable from the wet switch to cooling control voltage transformer as shown in the wiring diagram. One or two drops will cause wet switch to turn off a unit alerting a. Image 2 depicts hydrophilic pad image 3 depicts integral feet image 4 depicts stainless steel sensors the wet switch flood detector is a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. Simple 5 wire installation. 2 amp contact rating.
It now has a built in test and reset button. Connects to 24 vac. It now has a built in test and reset button for easier installation. Controlling selected components system components such as compressors electric valves condenser model no. Wet switch flood detector a solid state control designed to help prevent flooding damage to carpets walls furniture ceilings etc. Etl listed file number 3146992.
Cut common wire of transformer. Turns system off when detecting moisture due to condensate or drain leaks. Restore power to the system. Connect wiring as shown in the diagrams on page 2. Connect green wire from wet switch to common wire that was cut from transformer in step 4. Wires may be extended as necessary but avoid excess run lengths.
Now has a built in test and reset button for easier installation. More than one unit may be connected to a system.
