Vehicle specific wiring diagram acura integra 1986 1993. An hks fcd a fuel controller must be used as additional fuel tuning.
Ecu Wiring Diagram Inside Supercharging Amp Turbo
Hks fcd wiring diagram. If so it may cause an electric shock or damage the vehicle. Then in the window that pops up it should show you a picture of the fcd and right under it should say download installation manual. The location of the correct ecu wires is found by position and not color. Confirm that the diagram shown corresponds to your vehicle by referencing the factory repair manual. Click on that and that should tell you how to wire it up. Salva salva hks ecu wiring per dopo.
To pressure signal wire marked p on ecu diagram. Hks fcd itself cannot control fuel. The following diagrams may differ slightly depending on vehicle year or model california or federal. The hks fcd consists of has 4 wires. To wiring loom side of original pressure signal wire. The electronic signal from the fcd will raise the fuel cut level to accommodate for the additional boost without triggering fuel cut andor an engine diagnostic light.
The red and black wire splice into the original ecu wires. Locate the engine control unit ecu using the diagram below. The yellow and white wires. Use the provided crimp connectors and install them in the correct positions. Pressure sensor air flow signal note. The fcd installation is designed to be easily integrated with the vpcf con or factory ecu harness.
Make sure all connections and wiring are correct and do not become shorted or disconnected. 0 0 mi piace. Some spplcatons have multiple p signals use afr for afr and pfcd for fcd a behine govedox i rpm signal s speed sensor t throttle position sensor injector signal all diagrams are shown from the wire side of the harness honda.
