Inspect wiring and ensure connections are correct before applying. This installation guide provides the basic installation wiring and programming information required to program the powerseries pc1616 pc1832 and pc1864 control panels.
Dsc 1864 And External Siren With Backup Battery
Dsc 1832 wiring diagram. Back wiring the keypads to the control panels is relatively straightforward. And each keypad will also have similarly named terminals to ma. This guide assumes that all of the components will work together. The power 864 supports 64 different zones but only 8 zones are available with the main board. Do not connect transf or mer to receptacle controlled by a s witch incorrect connections may result in ptc failure or improper operation. Pc161618321864 wiring diagram con1 batbat 1.
Minimum 14 64mm separation must be maintained at all points between batteryac wiring and all other. 165vac 40va dscptd 1640u class ii tr ansf or mer. All keypads will connect in parallel with the four keybus terminals. See the alarm wiring guide for more information. Shop on amazon if youd like to support this channel httpsamznto2dpjplt in this video ill go through the basic wiring of a dsc security alarm system. Pc161618321864 wiring diagram pc board cabinet stand off primary120vac60hz.
In the video below we show you the basics of wiring a dsc alarm system with typical devices used on any installtion. Insert standoff into cabinet mounting hole in the desired location. 2gig asc gsm compatibility concord 4 dsc 832 5010 dsc 1616 1832 dsc 4020 dsc 9047 dsc alexor dsc impassa dsc neo lynx plus nx6 8 nx6 8xlsx simon xt vista 10p15p20p. Actual wiring diagrams and pictures are provided for real dsc products. Do not connect transformer to receptacle controlled by a switch incorrect connections may result in ptc failure or improper operation. Installation 3 pc161618321864 wiring diagram pc boar d cabinet stand of f pr imar y120v a c60hz.
This guide shall be used in conjunction with the powerseries pc161618321864 reference manual. Ill take you through what all the. 165vdc 40va dscptd 1640u class ii transformer note. 165vac 40va dscptd 1640u class ii tr ansf or mer no te. These terminals are named after the standard colors of 22 gauge 4 conductor alarm wire. Red blk yel grn.
Dsc power series 1616 1832 and 1864 basic wiring back to main wiring an alarm system can seem intimidating if youve never done it before but its really quite simple and is all low voltage. Position circuit board mounting holes over standoffs. Pc161618321864 wiring diagram pc boar d cabinet stand of f pr imar y120v a c60hz. This is the master wiring diagram for a power 864 main panel. Press firmly on board to snap in place.
