Deutsch connector wiring diagram. I think i like the new. Typical applications include on or. The dtm is the connector to be used in harsh environmental application where reliable signal circuits are critical to operating performance. Deutsch connectors the basics. Gently release the locking finger inside the connector by moving it away from the contact with the screwdriver end of the deutsch dt rt1 removal tool. Deutsch dtm series connectors are the answer to all of your smaller wire gauge applications.
Your deutsch connector headquarters cart 000 0. No products in the cart. We will use a three contact plug dt06 03s in the example below. The deutsch dt connector system is the preferred choice for many top nascar irl ccws formula 1 alms grand american road racing association racing teams and by leading manufactures due to its. The maximum current amp draw on each pin would be 75 amps continuously. Deutsch dt seriesthis size 16 connector.
Deutsch dtm seriesthis size 20 connector will accommodate wire sizes from 22 16 gauge depending on which contact is used. While holding spring finger in the release position pull the wire straight out from the rear of the connector. Your deutsch connector headquarters. Connectors and wire harnesses. Up to now i have used weather pack connectors. The locking finger only needs to move a slight amount to release the contact.
Here is some help in understanding the deutsch numbering system. To become familiar with the deutsch connector read the parts description below while referencing the 12 place con nector illustrated in figure b 3. Building on the dt design strengths the dtm connector line was developed to fill the need for lower amperage multi pin inexpensive connectors. Dtm connectors come in 2 3 4 6 8 12 pin configurations. In this how to video i talk about deutsch connectors. Alignment tabs andor external latch sec.
Deutsch dtm series of transportation connectors feature a miniature contact with an enhanced design based on the world class field proven deutsch dt series. I assemble and disassemble the new to me deutsch connectors. Pinout of sae j1587 deutsch 6 pin connectorj1587 is an automotive diagnostic protocol standard developed by the society of automotive engineers sae for heavy duty and most medium duty vehicles built after 1985. It is important to note the dt and dtm series 8 way and 12 way plug and receptacle housings are available in four different keyed configurations and are identified by distinct colors for each key position as follows.
