Delco 10si breakdown 2 2012 j n auto electric inc. This diagram shows the simple wiring diagram for negative ground delco si series alternators the ignition switch is most commonly powered from the starter battery stud but source may vary depending on application.
Diagram Based Wiring Diagram For Gm Alternator Completed
Delco 10si alternator wiring diagram. If you should be pleased with some pictures we provide please visit us this page again dont forget to talk about. Including but not limited to any installation and or repairs to the delco remy alternators. With key on power is then transferred through the no charge indicator light to the 1 spade on the alternator regulator connection. Assembly positions provides for proper exit of the wiring from the alternator. If you are converting from a 3wire 10si to a 1 wire regulator you can hook up all your stock connectors and run it as is. Used only for those that require the stock connector to fit snugly.
However thats wasted money unless you plan on cleaning out some wiring under your hood. It was also used in a lot of off road equipment so theyre generally cheap and easy to find. 10si 12si 15si alternator installation instructions. 10si and 12si are delco remy model number designations but not part numbers. The 10si has three terminals including those with a 1 wire regulator. Failure to use proper eye protection can lead to serious and permanent eye damage.
This diagram shows how to wire a delco gm internally regulated 3 wire alternator. Housing and collar installation in 10si 11si alternator delco remy 10si 11si 12si or bosch k1 alternators with 11si. We collect lots of pictures about delco 10si alternator wiring diagram and finally we upload it on our website. Many good image inspirations on our internet are the best image selection for delco 10si alternator wiring diagram. Only perform the mechanical functions that you are properly qualified to perform. This particular model 10si used in the 1970s and early 80s is the one youll find on the generation of gm cars most often used in demolition derbies.
The terminal is present on 1 wire regulators.
