Clipsal c bus wiring diagram. Electrical contractors or building companies are not bound to follow these prices and may charge more or less than. For more information about clipsal c bus see our home page section getting started getting technical how c bus works c bus network wiring. Relay units come in 4 channel 8 channel and 12 channel modules that can be wired to switch lighting circuits blinds low voltage devices and automate other systems. Residential smart wiring security and safety. The clipsal c bus system is a microprocessor based wiring system which controls lighting and other electrical devices. Maximum c bus current per.
It shows the components of the circuit as simplified shapes and the capability and signal contacts amongst the devices. Clipsal c bus wiring diagram wiring diagram is a simplified good enough pictorial representation of an electrical circuit. The clipsal catalogue number for this product is 5005c305b. Clipsal c bus network analyser tool 5100na. The c bus network bus is the communications wiring for the system consisting of an unshielded twisted pair utp cat 5 cable. C bus can control any type of load digital and analogue.
C bus cable type all c bus networks use an unshielded twisted pair utp cat 5 cable as the communications medium. The c bus din rail series relays are c bus output units that have volt free contacts that are rated at up to 10amps. View the c5031nl product features specifications documents and related faqs. The diagram opposite shows switches may be connected in parallel on any. C bus can control and automate any kind of electrical load from the onoff functionality of a lighting circuit to the analogue input of a dimmer switch. C bus single line diagram.
Wiring for 5508rvf series model load c bus ne twork ea r t h l i ne 2 n line 1 a mains supply 240vac 1 7 cat 5 c bus pa ch cord rj5 b3 0pl 5 4. 10 product range 5508d1a c bus eight channel dimmer with c bus power supply 220 240v 50 60hz1a. Remote off with these conductors being connected to c bus negative via the switch to action this state. C bus edlt classic c2000 series. C bus is a communications protocol based on a seven layer osi model for home and building clipsal manufactures a specific category 5 cable for use within electrical distribution panels. This cable has a pink outer the category 5 c bus network wiring uses a free topology architecture.
C bus voltage the standard c bus voltage should be 36 v dc this may vary slightly. It is recommended that the voltage be no lower than 25 v dc.
