In a view diagrams easy explanation of wiring the shaver socket to the lighting circuits ceiling rose and also to the rings socket outlet. To assist with the correct installation of this product please consult the wiring diagram.
Electrical Installation
Shaver socket wiring diagram uk. Fitting an electrical shaver point where and how to fit a shaving socket. Electric toothbrushes in the uk are normally supplied with. An accessory embodying a shaver transformer and one or more socket outlets. A shaver point is the only electric socket outlet permitted in a bathroom. Be sure where they are allowed to be fitted and understand the shaver socket regulations. A shaver supply unit complying with bs en 61558 2 5 may be installed in zone 2 of a location containing a bath or shower regulation 7015123 refers.
When wiring ensure to link the earth neutral and live wires after connecting the wires in your shaver socket to their corresponding terminals. Then connect the conductors. Shaver points can either be connected to a ring main spur via an fcu or run from a spur on a lighting circuit. This is a vital part of the process so if you need more information on this then ensure you check the wiring diagram carefully and follow the colour coding techniques. Advice on installing a shaver socket to update your bathroom. A shaver socket outlet with a transformer is called a shaver supply unit.
Two core and earth cable from the connection unit to the shaver socket. See a wiring diagram how to wire your shaver socket when installing it. Unlike the original the plug has insulated sleeves on the pins. This video is about wiring shaver socket. The term shaver supply unit means. Although surface mounted boxes can be purchased it is safer to install a flush mounted shaver point.
No because the neutral at the light switch is not a neutral at all its a switched live to feed the light. The earth connection should always be made to both the mounting box earth terminal and the shaver socket earth terminal. Bs 4573 british standard specification for two pin reversible plugs and shaver socket outlets defines a plug for use with electric shavers the pin dimensions are the same as those of the 5 a plug specified in the obsolete bs 3721930 part 1 as shown in the table above. Red to l and black to n1. You can wire a shaver socket from a junction box on an earthed lighting circuit or from a fused connection unit fitted with a 3amp fuse on a ring circuit spur run 1mm sq. Connecting the shaver socket in the way you describe would place it in series with the light when the light was switched off the socket would probably work if the lamp is a standard fillament lamp and the switch would short out the power to the socket when the light was on.
Wiring in the shaving point. Find out how to fit a shaving socket.
