Prins vsi wiring diagram. Ts 23 04 07 rk 26 10 07 1 jt 26 10 07 11 08072050 vsi wiring diagram 6 cylinder lpg without connectors 30 battery 12v 15 ignition switch petrol ecu manufacturer. Locate the thin light blue wire. Vsi lpg cng ecu manufacturer. Check our website regularly for diagrams certificates updates info bulletins and product information. This photo is the rear end of the plug facing the inner guard. 09999928 exhaust gas analyser multimeter oscilloscope prins vsi diagnostic software prins vsi serial interface prins vsi break out box part nr.
Vsi 8 hall sensor camshaft sensor lambda sensor with heater b1 40 46 hall sensor tanklevel sensor 12 49 48 lpg beeper lpg switch 8 pole connector yellow green brown orange yellow red black red yellow green ground black brown black grey grey grey brown grey red green orange purple white blue grey white red red red white 1 2 3. Engine control relay b7 c7 b6 c6 b5 t t oxygen sensor 1 bank 1 oxygen sensor 1 bank 2 injection module 1 2 3 4 5 6 injection module. The following functions are available with the vsi controller. Crd performance bolton the lpg conversion experts. Use this diagram to familiarize yourself with the function and location of each component before using the vsi controller. Prins vsi 1 and vsi 2 installation manual diagrams.
18070004 vsi wiring diagram 4 cylinder lpg without connectors 50 43 42 15 18 17 22 23 main ground vsi lpg ecu manufacturer. Prins vsi diagnostic software prins vsi serial interface prins vsi break out box part nr. 08070090 torque wrench 10nm portable light assortment drill bits 4 to 12 mm. Prins autogassystemen is not responsible for any damages to people or objects as a result of changes to prins products. A1 a2 a3 a4 a5 a6 b6 a7 a8 b1 b2 b3 b4 b5 b8 b7 vsi ecu c6 c1 c2 c3 c4 c5 c8 c7. Prins auto gas systems australia pty ltd fuel gauge reset relays fuel gauge reset relays remove the drivers side kick panel and locate the large white multi pin plug.
Locate the thin violet silver dots wire. Published september 27 2012 by webmaster. Refer to diagrams a b 12v wire. Lpg conversion petrol vehicles. Vsi lpg cng ecu manufacturer. 08070090 torque wrench 10nm portable light assortment drill bits 4 to 12 mm assortment cutters ø 20 30 50 70 mm punching tool ø 70 mm round file portable drill or pneumatic drill.
