Many folks tend to hook up the power feed wire in the wrong place since its not specified in the pertronix wiring diagram and that leads to a very early failure. Ok so i misplaced my diagram for the connections of the ignitor and coil.
Pertronix Distributor Wiring Question For A Bodies Only
Pertronix wiring diagram. Pertronix ignition wiring diagram data wiring diagram schematic pertronix ignitor wiring diagram wiring diagram consists of several in depth illustrations that display the connection of assorted things. If not the arrangement will not function as it ought to be. Mar 25 pertronix has also sent me a diagram showing the correct wiring. Each component ought to be placed and linked to different parts in particular manner. Bryans right any switched 12v is ok to run the pertronix. It shows the wire running from the alternator regulator to the positive side of the coil along with the red wire from the module and the wire from the ignition ballast being removed.
Mustang petronix ignitor 1965 1973 installation. As far as killing your tach you dont need to worry if you use the correct factory harness. Figure 1 wiring diagram conventional points system with ballast resistor figure 2 wiring diagram ignitor system without ballast resistor figure 3 wiring diagram ignitor system with ballast resistor note. You need 12v into the red 3 ohms resistance between the red and black rather than both attaching at the coil as drawn. For optimum performance purchase and install the flamethrower ii high performance coil. Attach the red ignitor ii wire to the positive coil terminal.
Discussion starter 1 jun 26 2005. The ignitor ii ignition can be used in conjunction with most ignition coils rated at 045 ohms or greater. Download pertronix wiring diagram with factory tach. Joined mar 10 2005 520 posts. It includes instructions and diagrams for various types of wiring techniques along with other products like lights windows etc. Jump to latest follow 1 18 of 18 posts.
Attach the black ignitor ii wire to the negative coil terminal. Pertronix ignitor wiring diagram pertronix ignition wiring diagram pertronix ignitor ii wiring diagram pertronix ignitor iii wiring diagram every electrical arrangement is made up of various different components. Went to the pertronix site and not available. A resistor wire or ballast. Anyone have the diagram that you. Pertronix ignitor and coil wiring diagram.
Pertronix wiring diagram with factory tach.
