Cee System Iec 60309 Ip Code Ac Power Plugs And Sockets
Iec 60309 wiring diagram. Tapered wiring pockets to ease insertion of stranded wire. En 60309 1 en 60309 2 standards have been adopted by the european members of cenelec and are internationally accepted including in north america. Voltage the voltage is determined by the location of the female ground contact relative to the housing keyway. Connects to a 332p6w male. Standard iec 60309 1 and iec 60309 2. Stayonline provides the most reliable power cord supply chain management.
Classified to iec standards 60309 1 and 60309 2 base device. Iec 60309 formerly iec 309 and cee 17 also published by cenelec as en 60309 is a series of international standards from the international electrotechnical commission iec for plugs socket outlets and couplers for industrial purposes. Pin and sleeve device housings are color coded by voltage rating. 4 wire 125250vac 440 460vac 60hz 3 pole. Order online or call 1 800 590 8610. We can leverage our usa and off shore molding capabilities to deliver the right cord when you need it.
Ceetyp clock face positions in accordance with iec 60309 1 iec 60309 2 ul 1686 north american rating voltage ac except where noted let us help you find the right solution for your power path needs. Deep pockets with clear markings keep bare conductors isolated project name. Iec 60309 wiring devices are manufactured with high quality polyamide 6 material and nickel plated brass contacts to meet the toughest industrial and environmental conditions. North american international and european iec 60309 pin and sleeve devices are manufactured to en 60309 1 and en 60309 2 standards. Iec 60309 plugs and connectors use different pin configurations for different amperages and voltages. Iec 60309 pin sleeve wiring device information.
Iec 60309 1 iec 60309 2 clock diagram a guide to color numbering and ratings in order to prevent connecting devices to an incorrect power source the iec 60309 standard specifies both physical attributes and marking requirements to prevent such mismatch. The maximum voltage allowed by the standard is 1000 v dc or ac. 332r6w outlet rated for 32a 250v cooper part ah332r6w in stock ships within 24 hours. En 60309 1 specifies general functionality and safety requirements for industrial high current power connectors. The dimensions of the device and ground. Technical drawings wiring diagram for iec 60309 pin sleeve cee typ devices all specifications are subject to change without notice.
The maximum current 800 a. This standard calls out a singly rated non interchangeable configuration for every voltage and type of service throughout the world. Classified to iec standards 60309 1 and 60309 2 base device. Classified to iec standards 60309 1 and 60309 2.
