Lighting solutions product reference 5 optanium high efficiency instant start electronic fluorescent ballasts for t8 lamps engineered to optimize lighting performance and maximize energy savings optanium ballasts fully support the wide variety of t8 fluorescent lamps on the market. A wiring diagram is a streamlined standard pictorial representation of an electric circuit.
Pdf Electronic Ballast Circuit Configurations For
Fluorescent lamp wiring diagram pdf. It is good practice to number the phase and the neutral wires at the db for easy identification as one circuit. The filaments light up and instantly warm up the tube. When an ac voltage is applied to a tube light fixture the voltage passes through the choke the starter and the filaments of the tube. Cut the wires shown as the diagram above. It shows the components of the circuit as simplified shapes and the gift and signal links between the devices. The starter is made up of a discharbe bulb with two electrodes next to it.
Draw earth wire to the fluorescent light fitting and connect to the earth point of the magnetic ballast. Led light tube wiring diagram. Incandescent lamps 3 incandescent lamp characteristics 4 fluorescent lamps 5 fluorescent lamp circuits 6 fluorescent lamp starters 7 fluorescent lamp. This post fluorescent light wiring diagram tube light circuit is about how to wiring fluorescent light and how a fluorescent tube light works. Do not pull original wire leads from lampholders. 4 re wireing it per below diagram by wire nuts blue lamp sl15t wiring for 2 fluorescent linear lamps white blue caution.
Assortment of fluorescent ballast wiring diagram. Some are rated for only 120 volts. Newer fluorescent ballasts are usually rated for both 120 volts and 277 volts. This may cause loose connection on the lampholders. In most cases when we buy a fluorescent light it comes in a complete set with all wire connected. Make sure the connection is tight.
Ballast wiring diagram shows how the ballast is wired to the lamps ballast wiring diagram. It reveals the components of the circuit as streamlined forms and the power and also signal links in between the gadgets. Fluorescent lamps use a ballast which transforms line voltage to a voltage to start up and operate the lamps. Characteristics 8 mercury lamps 9 troubleshooting. Rk primer of school lighting. Schematic diagram for wiring fluorescent lamp circuit.
Fluorescent lamp wiring diagram pdf wiring diagram is a simplified normal pictorial representation of an electrical circuit. And 10 cleaning and cleaning. This principle of the choke is exploited in lighting a fluorescent tube light. The wiring process of fluorescent tube lamplight with ballast starter is quite easy and simple. Cut and strip and use wire nuts to install the new ballast in the fixture. Open the wiring cover to expose the fluorescent ballast.
Fluorescent lamp holders within fixture shall be rewired to line voltage and will no longer operate the original fluorescent lamp.
