Cm pdt 9 wiring diagram. Cm pdt 9 occupancy sensor and pp 20 power pack acuity read description duration. 4 to 7 stalls cm pdt 9 place within visual sight of the main entry door more than 7 stalls multiple cm pdt 9 contact your acuity sales representative for assistance. Lens options include large motion extended range small motion standard range and bi directional for hallways. The lighting is then controlled in blocks similar to manual switching. Cmr 9 ts cmr 007a typical wiring single relay 12 6 0 ft 6 12 37 18 0 m 18 37 side view 0 ft 9 0 m 27 top view 12 6 0 ft 6 12 37 18 0 m 18 37 standard range 360º lens note. Screw axis is aligned with a long detection segment.
Manufacturer cm pdt 9 color white unspsc 39122236 brand or series cm pdt series coverage degrees square feet 360452 installation type ceiling mount sensor type passive infraredmicrophonic time delay type adaptivemanual timer range 30 seconds to 20 minutes voltage 1224v dc use with pp20 sku spec sheet. The lighting is then controlled in blocks similar to manual switching. Restrooms with stalls large storage areas with shelving and libraries with study carrels are also easily and cost effectively controlled by the ncm pdt 9. The cm is a low voltage sensor that easily mounts directly to a ceiling tile or a metallic grid. Mko electric 4886 views. By installing multiple cm pdt 9s on 30 ft 914 m centers large control zones are created typically one per circuit of lighting.
Read below this video shows you how to wire an occupancy sensor cm pdt 9 and power pack pp 20 by acuity controls. Coming from the power pack you have 2 blue wires. Ceiling mount sensors are offered in a multitude of configurations which address many applications. The lighting is then controlled in blocks similar to manual switching. Restrooms with stalls large storage areas with shelving and libraries with study carrels are also easily and cost effectively. Pdt 9s on 30 ft 914 m centers large zones are created typically one per circuit of lighting.
Wiring diagrams d adc dimming options r relay option blk 120 v orn 277 v d p adc photocell dimming options pp20 fixture ballast or load 2 fixture ballast or led. Pdt 9s on 30 ft 914 m centers large zones are created typically one per circuit of lighting. Restrooms with stalls large storage areas with shelving and libraries with study carrels are also easily and cost effectively controlled by the ncm pdt 9.
