Eec v wiring diagram. Eec v is harder to deal with but once the right tools are had and ford releases some of its locked files it will be a lot easier to use trust me. The eec v module is located beneath the dashboard behind the glove compartment. The el eec v wiring connector is the standard ford 60 pin connector as used on the xf 41 efi ebii 40 and ed 40 eec modules. They show a great wiring harness for both eec 4 and 5 and newer if you use a tweecer you can delete all your smog junk egr tab air pump and you wont get a check ingine lite can also change injector firing order for different cams i use one on my 91 ranger 50 efi really straightened it out. It is pop riveted to its bracket for security and a port for connection to the obd diagnostics is provided on the underside of the dashboard in the change cubby to the right of the steering column. Is located on the lower row far left when the wiring connector is facing somewhere pretty.
Does anybody have a diagram for a 104 pin eec v for an ef. Eec handbook ford fuel injection and eec iv electronic engine control by down is an overview of the eec system and a link to a typical wiring. I have a diagram here for it but it is imposible to read the pin. Seperate injector wiring thats not how my ef is wired. The el 40i eec v module has the following features 1. 1996 ford pickup with 49l 50l 58l engine with 4r70w or e4od automatic.
The eec v pcm has a 104 pin connector and on the back side of the connector wire side are embossed a few numbers on the back side to further aid you in correctly identifying the pins circuits. I am after the wire for the water temp sender. The illustration above and pin out table below apply only to. Please note that pin 1. All of these systems were the mass airflow type and used coil packs modular engines do not use a distributor. Ford eec 5 pinouts as follows.
Thu apr 19 2007 839 pm. Remember that eec iv is old eec v is the future and probably outdated as i write this an eec vi will be on the way in a few years. Eec iv 19911993 the eec iv computer was installed on the earliest modular engines in full size ford cars. Ford used this computer system throughout the 1980s and eec v replaced it in 1994. Low speed fan pin determined by edfloc scalar 0 pin 28 1 pin 45 2 pin 19 low speed pump pin determined by fplloc scalar 0 pin 19 1 pin 43 2 pin 79 for datalogging wideband through egr input on eec v pin 65 is the 0 5v analog input.
